Armouring steel wire is made of galvanized steel wires in round and formed sections. These wires are commonly used for the protection (prevention of accidental damage), the provision of additional strength, and for earthing of all grades of electric cables.

T/S: 30-50kg/mm2 or 350-500N/mm2

Elongation: 10% hot-dipped

Packing: 500 kgs Pattern laid coils, ID 450 mm, OD 800 mm

Inner 4 metal strips with 4 d-ring. By plastic inside and PE woven cloth outside.

length:0.9mm about 100021m per 500kgs coil

1.25mm about 51903m per 500kgs coil

1.6mm about 31679m per 500kgs coil
